High efficacy 125LM/W. Seamless connection without light leakage. Fast installation and easy maintenance. Optimum glare control. Shining free and uniform light. Individual and continuous row optional.
Product family description
Direct or Indirect option
Luminaire housing from extruded aluminium profile with 65mm wide light exit;
Designed for continuous lighting systems suitable for office or public lighting
Surface white powder coated; luminaire profile with pre-assembled converter unit can be pre-mounted; light inset can be installed without tools;
High Performance Opalcover for uniform illumination; micro lens incl. grille reflectors for homogeneous illumination and reduced luminance;UGR<17
Energy-efficient LEDs with very good colour rendering; binning initial ≤ 3 MacAdam; available in the light colours 3000K and 4000K; CRI≥ 80; min. 90 % of the luminous flux after 50000 hours;
Protection IP 20; IO40
optionally non-dimmable or DALI-2 control
|
ousing materials |
6063 extrusion aluminum alloy |
|
Size |
L1200*w65*H75mm; 25W@3200lm L1500*w65*H75mm;31W@4000lm L2400*w65*H75mm;50W@6000lm L3000*w65*H75mm;63W@8000lm |
|
Housing color |
Black, White, |
|
Light source |
high efficiency SMD 2835 |
|
Color |
Warm white, neutral white, cool white |
|
Kelvin |
3000K/4000K/ Tunable (3000K-6500k) |
|
CRI |
80+,90+, |
|
Luminous efficiency |
125lm/W @CRI80 |
|
Beam angle |
120°(lens+micro reflector),UGR<17 |
|
Continuous 3 |
YES |
|
Finish |
Matt White; Black |
|
Voltage |
AC200-240V/ AC90-130V |
|
Dimming |
DALI, 0/1-10V, |
|
Driver |
PF>0.95 flicker-free isolated constant current driver |
|
Installation |
Suspended or surface mounted |
|
Warranty |
3 years; 5 years |
| Order Code | CCT | IP Rating | LED Power | System Power | CRI | System Output |
| LN120025W30K | 3000K | IP40 | 22.5W | 25W | Ra>80 | 3200LM |
| LN120025W40K | 4000K | IP40 | 22.3W | 25W | Ra>80 | 3200LM |
| LN150031W30K | 4000K | IP40 | 25.6W | 31W | Ra>80 | 4000LM |
| LN150030W40K | 3000K | IP40 | 25.6W | 31W | Ra>80 | 4000LM |
| LN240050W30K | 4000K | IP40 | 47.4W | 50W | Ra>80 | 6000LM |
| LN300063W30K | 4000K | IP40 | 58.9W | 63W | Ra>80 | 8000LM |
| order code | colour | length | LED pcs | LED power | power consumption* | weight | EEI | |
|---|---|---|---|---|---|---|---|---|
| B120210w | white | 500 cm | 600 | 48 Watt | 40 Watt | 0,07 kg | A+ | |
| B120210NW | neutral white | 500 cm | 600 | 48 Watt | 40 Watt | 0,07 kg | A+ | |
| B120210WW | warm white | 500 cm | 600 | 48 Watt | 40 Watt | 0,07 kg | A+ | |
| B120210SW | super warm white | 500 cm | 600 | 48 Watt | 40 Watt | 0,07 kg | A+ | |
| B120210uw | ultra warm white | 500 cm | 600 | 48 Watt | 40 Watt | 0,07 kg | A+ | |
| B120210AW | ambiance white | 500 cm | 600 | 48 Watt | 40 Watt | 0,07 kg | A | |
| B120210B | blue | 500 cm | 600 | 48 Watt | 40 Watt | 0,07 kg | B | |
| B120210xx | neutral white | 2000 cm** | 120 per m | 9,6 Watt per m | max. 9,6 Watt per m | 0,28 kg | A+ | |
| B120210xx | warm white | 2000 cm** | 120 per m | 9,6 Watt per m | max. 9,6 Watt per m | 0,28 kg | A+ | |
| B120210xx | super warm white | 2000 cm** | 120 per m | 9,6 Watt per m | max. 9,6 Watt per m | 0,28 kg | A+ |
